Photo 2......

Stock No:                                 9142

Specifications:
Manufacturer:                    Corsteel (Canada, Concord Ontario)
Model:                                 C-1834
Year manufactured:           1982
Tonnage:                             150 Tons
Stroke:                                18"
Daylight:                             34"
Shut Height:                       16"
Bed area:                            22½" Front-Back x 54" L-R
Ram area:                           22" F-B x 72" L-R
Piston Diameter:                14"
Main Motor power:            30 HP
Electrics:                             575V / 3Ph / 60 Hz

Speeds:                               Advance-   200 IPM
                                            Pressing-     33 IPM
                                            Opening-   210 IPM

Operation Pressure:          2000 psi.
Oil Reservoir Cap.:           196 Gal.
Hydraulic Components:    Abex-Dennison
Height above floor:           131"  w/ ram down
Shipping dimensions:         72" L-R x 88" F-B x 131" H. (can be shipped in one piece)
Weight:                              42,000 lb.

Equipped With:
    *    Fully Gib-guided Ram
    *    Quick Stroke Adjustment
    *    T-slotted Bed
    *    T-slotted Ram
    *    Inching Controls w/ Dwell or Cycle Timer
    *    Double Palm anti tie-down Control Buttons
    *    Freestanding Control Console

Notes:
    This quality late model press is of all fabricated construction.  It has the unique features
such as gib-guided ram, (Gap Frame).  Showing NO rust or scoring, it is ready to go back into production.  It is already removed for shipping, and is ready to load on your carrier.  It can be shipped in one piece by truck.

Price (FOB open truck, near Toronto, Ontario).  .  .  .  .  .  .  .  .  .  .  .  .  $ 32,500.00 USD
