Specifications:
Material : Hot Rolled, Cold Rolled, Electrogalvanized,
Galvanized & Painted Steel, Aluminum
Material Thickness : .016" to .187"
No. of Levelling Rolls : 11
Operating Speed : 26 to 14 Ga. up to 150 F.P.M.
12 Ga. to 3/16, up to 100 F.P.M.
Maximum Coil Weight : 20,000
Maximum Coil Width : 60"
Coil I.D. Range : 18" to 20" (Exp. with Rubber Rings)
Coil O.D. Range : 30" to 60"
Electrics-Motors : 480 / 3 / 60
Controls : 120 / 1 / 60
Main Drive : 75 HP
- Coil Car
Coil Weight : 20,000# Max.
Self Contained Hydraulics
- Uncoiler Mandrel Type
Capacity : 20,000#
Coil O.D. : 60" Maximum
- Drum Expansion Range : 16-1/2" to 21"
Tension Brake
Holddown Roll
- Flattener
Pinch Rolls : 6" Diameter x 66" Face
Work Rolls : 3-1/2" Diameter x 66" Face
- Flying Die Type Cutoff Press
Capacity : 100 Tons (1/8 Off B.DC)
Stroke : 3"
Wichita Clutch & Brake
- Runout Belt Conveyor Table
- Stacker
16' Maximum Length
With Side Discharge
- Under Power
- Operating Equipment has been modernized with some digital controls
Price: $95 000 USD
|
