Stock No:                      C1621

Specifications:

Manufacturer:              Kitchen and Wade, Halifax, England
Style:                             Double Housing Type, 4 axes of Travel
                                       (i.e 1 axis (X) table movement, 1 axis (Z) rail movement, 1 axis (Y)
                                       head cross travel movement, 1 axis (Z) quill movement)

Table size:                    120" x 53"
Table Design:               6 T-Slots and 12 rows of T-nut holes
Vert. Rail Travel:        34"
Head Travel, Rail:       53"
Quill Travel:                 10" approx.
Spindle Nose:               #4 MT
Spindle Power:             5 H.P.
Spindle Speeds:            22-1000 RPM
Table Power:                5 H.P., Hydraulic, variable speed
Hydraulics:                   Abex-Dennison PV15-2R1A-C00 Pump, Dennison Controls
Overall Dimensions:    20'4" long x 10' wide x 10'6" high
Weight:                         Full Load - 20 Tons (est.)

Equipped With:

        *        FULL PENDANT CONTROL (counterbalanced)
        *        LOAD METERING

Price:   FOB Montreal . . . . . . . . . . . . . . . . . . . . . . . $ 18,000.00 USD
                                                                                or $ 28,800.00 CAD
